GermanStainless Steel Wire
Austenitic / Duplex Steel / Nickel Alloy / Cobalt Alloy304/304L/304M/304H Stainless Steel Spring Wire High Quality Wire with High Strength
MTSCO is a professional supplier of steel wire with complete production technology and rich management experience. We produce spring wire, electrolytic polished wire, fine wire, wire for netting, hose wire, welding wire, cold heading, locking wire, and other products. Our main materials are stainless steel and alloy steel, and the raw materials we use are from the biggest and most well-known steel mills in China, we can supply wire in sizes ranging from 0.15 mm to 16 mm in diameter.
Send Inquiry
304/304L/304M/304H Stainless Steel Spring Wire High Quality Wire with High Strength
| Material | Stainless Steel Wire |
| Grade | 300series (301, 302, 304, 304L, 304H, 304N, 304ES, 316L, 321...) 130M, 200CU, 201CU, 202, , 410, 420, 430,etc |
| Standard | ASTM A580, JIS G4309, EN 10088-3, GB/T4240, etc |
| Size | φ0.15mm-φ16mm; or according to customers' requests |
| Surface | Bright, matte ,downy, electrolysis bright ,cloudy ,plain ,black,etc |
| Condition | Annealed and Soft, 1/2 hard, 3/4 hard and full hard |
| Type | Spring Wire (B-SPR/D-SPR) |
| Packing | Woven bag, core, wooden reel, etc |
Advantages of stainless steel wire:
1. Highly resistant to rust and corrosion
2. High strength and robustness
3. Highly elastic and impact resistant to fire
| Steel grade | DIN | Chemical composition | ||||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | Other composition | ||
| 304 | WNr1.4301 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤0.03 | 8.0-10.5 | 18.0-20.0 | ≤0.6 | |
| 304M | ≤0.06 | ≤1.0 | ≤2.0 | ≤0.040 | ≤0.03 | 9.0-10.0 | 18.0-20.0 | N: ≤0.08 | ||
| 304MD | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.045 | ≤0.03 | 9.0-10.0 | 18.0-20.0 | ≤0.5 | ||
| 304MA | ≤0.08 | ≤1.0 | ≤2.0 | ≤ 0.045 | 0.01-0.03 | 8.0-10.5 | 18.0-20.0 | Cu:1.0-3.0 | ||
| 304MN | 0.03-0.06 | 0.02-0.06 | 1.8-2.5 | ≤0.040 | ≤0.012 | 9.0-10.0 | 18.0-19.0 | ≤0.6 | Cu:≤0.6 | |
| 304CU | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.040 | ≤0.03 | 8.0-10 | 17.0-19.0 | ≤0.6 | Cu:3.0~4.0 | |
| 304H | 0.067.08 | ≤1.0 | ≤2.0 | ≤0.040 | ≤0.03 | 8.0-9.0 | 18.0-20.0 | ≤0.6 | Cu:≤0.6,N: ≤0.08 | |
| 304H1 | 0.06-0.08 | ≤1.0 | ≤2.0 | ≤0.040 | ≤0.03 | 8.0-9.0 | 18.0-20.0 | ≤0.6 | Cu：≤0.6 | |
| 304HD | «0.05 | 0.25-0.55 | 1.6-2.0 | ≤ 0.035 | ≤0.015 | 8.5~8.9 | 18.0-18.5 | Cu:≤.5-2.0,Tol AI:≤0.015 | ||
| 304HC | ≤0.06 | ≤1.0 | ≤2.0 | ≤0.045 | ≤0.03 | 8.0~10.5 | 18.0-20.0 | Cu:1.0~3.0,N:≤0.08 | ||
 |  |
Application for 304 stainless steel wire:
304: Kitchen appliance and generally purposo
304M: Twister,kitchen appliance,screw cap,wire netting
304MD: DDM use
304MA: Non-magnetism
304MN: The 304m after added content of Mn
304CU: Cross bolt,screw
304H: Steel wire,spring,tight wire,chains
304H1: Steel wire,spring,tight wire,chains
304HD: Preliminary cold heading
304HC: Cold heading(hexagon bolt)
| Steel grade | Physical Property | |||
| Y.S | T.S | EL. | HRB | |
| 304 | 220 | 586 | 63 | 69 |
| 304M | 225 | 560 | 55 | 72 |
| 304MD | 210 | 575 | 62 | 72 |
| 304MA | 225 | 590 | 75 | 79 |
| 304MN | ||||
| 304CU | 190 | 505 | 56 | |
| 304H | 312 | 590 | 55 | 72 |
| 304H1 | 235 | 610 | 64 | 75 |
| 304HD | 212 | 540 | 75 | 85 |
| 304HC | 225 | 510 | 62 | 65 |
MTSCO is a professional supplier of steel wire with complete production technology and rich management experience. We produce spring wire, electrolytic polished wire, fine wire, wire for netting, hose wire, welding wire, cold heading, locking wire, and other products. Our main materials are stainless steel and alloy steel, and the raw materials we use are from the biggest and most well-known steel mills in China, we can supply wire in sizes ranging from 0.15 mm to 16 mm in diameter. Our factory is well-equipped and our products conform to ASTM, DIN, GTB, JIS, JSG, and other international standards. We have experienced foreign trade staff with high-quality service and can produce high-quality products according to customers' requirements.
Manufacturing Experience
Plant Area
Max Diameter of Welded Pipe
Annealing Furnace Length
What Grades Can We Provide?
Nickel Alloy
NI-MO: N10001,N10665,N10675...
NI-CR-MO: N10276,N06022,N06035,N06455,N06002...
NI-CR-MO-CU: N06030,N06200,N08031,N08825,N08020...
NICR-MO-W: N06230...
NICKEL: N02200,N02201...
NI-CU: N04400,N05500...
NI-CR-FE: N06600,N06601,N06690,N08800,N08810,N08811...
NI-CR-MO-NB: N06625,N07718...
Austenitic
304/L/H/N, 316/L/H/N/Ti, 321/H, 309/H, 310S, 347/H, 317/L, 904L...
Duplex Steel
31803, 32205, 32750, 32760...
Cobalt Alloy
Alloy 188/ UNS R30188, Alloy L-605/ UNS R30605, Alloy S-816, Alloy 6B, UMCo50, FSX-414, MP-159...
Feedback:
-304/304L/304M/304H Stainless Steel Spring Wire High Quality Wire with High Strength
Send Inquiry by feedback form learn more about product detail, price, etc.
Your email address will not be published. Required fields are marked *
FAQ
1. Can you provide samples?
Of course, We can provide a few sample tubes for you to inspect and experiment.
2. Can we mark our logo on the product?
3. What is your packing?
4. What inspection will you do?
5. What certificates do you have?
6. What is your minimum order quantity(MOQ)?
7. How long is your delivery time?
8. What is your terms of payment?
